IntegraRack IR-T1 TileBallast No Penetration Tile Roof Mounting System

IR-T1 TileBallast™ No Penetration Tile Roof Mounting System

• Aeronautical Wind Tunnel Tested at 165 MPH with 3:1 Safety Factor
• No Penetration
• No Tile Removal
• 4x Faster Install Times
• For Use With All Rail Systems
• Integrated Flex Point Prevents Bolt Tension From Cracking Tiles

The IR-T1 is the first of its kind and the only tile roof hook that requires no removal of tiles and no roof penetration at all. The IR-T1 TileBallast™ System is 4x faster to install than traditional tile roof hooks and much stronger, since our proprietary installation system actually increases the overall strength of the entire roof structure. When installed using our test proven IntegraGel Fast Setting Industrial Strength Two Part Epoxy, each bracket uses the weight of the heavy concrete tiles which are nested and overlapping each other. The IR-T1 has been tested at the George E. Boeing Aeronautics Department Wind Tunnel and is proven to withstand over 165 MPH wind speeds with a 3:1 safety factor, making it the most extensively tested solar roof mounting bracket ever. One tube of IntegraGel Epoxy is good for up to ten mounts.

Each IR-T1 comes with a strong, integrated upright mount that can be attached to any rail system. The simplicity of this system allows for extremely fast and easy installations. With no need to remove and replace tiles on the roof, installers are much less fatigued on large jobs. Many installers see increased sales with home-owners that are worried about potential leaks and love the benefits of a non-invasive system.

• Works with most all styles of concrete roof tiles with at least 1.25 inch thickness and 11.75-15.5 inch spacing. Only recommended for use with concrete roof tiles.

This product conforms to UL 2703 Mechanical and Bonding requirements.
