Outback Power Mojave Grid-Hybrid 8000W 48V Inverter

Continuous power8,000 W
Nominal voltage48 V

$3,430.00

In stock

Compare

Works with: 48 V systems

Questions? Call (727) 761-7772

SKU OGHI8048A

Pairs well with

This item: Outback Power Mojave Grid-Hybrid 8000W 48V Inverter$3,430.00
AIMS Power Lithium Battery 48V 200AMP LiFePO4 Industrial Grade$4,440.00Details of AIMS Power Lithium Battery 48V 200AMP LiFePO4 Industrial Grade
Victron Energy Modular fuse holder for MEGA-fuse$35.70Details of Victron Energy Modular fuse holder for MEGA-fuse
Dakota Lithium 48V 96Ah Deep Cycle LiFePO4 Battery$2,775.00Details of Dakota Lithium 48V 96Ah Deep Cycle LiFePO4 Battery

Total for 4 items: $10,680.70

Overview

Description:

The Mojave™ platform combines the latest power electronics and control technology with the old-school muscle and practical features that define OutBack Power™.

The Mojave inverter continues the impressive legacy of robust off-grid and grid-hybrid performance for which OutBack Power’s FX, FXR and Radian platforms are well known. But it doesn’t stop there. The Mojave inverter does away with external system controllers and includes an integrated wiring compartment for faster, clutter-free installation.

The OGHI8048A comes ready to AC-couple with most grid-tied inverters and 48 VDC batteries on the market today. It’s the easy way to add the economic and resilience benefits of energy storage to existing residential PV systems.

On-grid or off, be ready for anything.

Highlights:

Show the full description

Be ready for anything with off-grid capability
Easily start motors and compressors commonly found in freezers and HVAC systems, outpacing other inverters
Seamlessly AC-couple with UL 1741-SA listed grid-tied inverters up to 8kW for easy addition to existing solar PV systems
Take ownership of your energy in the face of time-of-use rates, demand charges and net-metering changes
Connect to the intuitive user interface via integrated Wi-Fi hotspot and a smartphone, tablet or laptop
Access OPTICS RE™ via Ethernet or Wi-Fi internet connection
Easily add a generator or other secondary AC source
Quickly and easily install with mounting plate and roomy integrated wiring compartment

Features:

Model: OGHI8048A

AC Input/Output

AC Voltage: 120/240VAC (split-phase)
AC Frequency: 60Hz
Max Peak/Continuous AC Output Power: 10000VA / 8000VA (derate above 40°C)
Max Peak/Continuous Output Current: 42A / 34A
Total Harmonic Distortion: Typical: <2% | Max: <5%
Power Factor at Rated Power: 1
Idle Power: Invert Mode, No Load: 100W | Idle: 10W
AC Coupling: Up to 8kW

Battery

Nominal DC Battery Voltage: 48VDC
Battery Voltage Range: 40 to 64VDC
Battery Types: Flooded, AGM, Lithium-Ion*

Grid Interactivity

Supported Operating Modes: Immediate battery backup power, grid support (UL 1741 SA), net metering, non-export, maximum independence
Islanding Protection: Yes – IEEE 1547 compliant
Supported Interconnection Standards: IEEE 1547-2003, IEEE 1547.1-2005

Mechanical

Weight (lb/kg): 133 / 60
Dimensions W × H × D (in/mm): 16 × 38 × 11.25 / 406 × 965 × 286
Chassis Type: Indoor-only, vented, NEMA 1, IP2X

Additional Features

Listings/Certifications: UL 1741 SA, CSA 22.2 No. 107.1, IEEE 1547-2003, IEEE 1547.1-2005
RoHS: Yes, directive 2011/65/EU
Operating Temperature Range: −4 to 122°F (−20 to 50°C)
Warranty Duration: 10 years
Field-Upgradable Firmware: Yes

Specifications

Electrical
Continuous power	8,000 W
Nominal voltage	48 V

Physical
Weight	133 lb

Identifiers
Brand	Outback
SKU	OGHI8048A
