Aims 5000 Watt 48V Pure Sine Wave Inverter PWRIG500048120S
- Continuous power5,000 W
- Nominal voltage48 V
$1,283.00
In stock
Works with: 48 V systems
Questions? Call (727) 761-7772
SKU PWRIG500048120S
Pairs well with
$1,283.00
Total for 4 items: $8,533.70
Overview
Aims Part Number: PWRIG500048120S Most people use the Aims PWRIG500048120S inverter for their off grid wind, hydro and solar systems. With 5000 watts of pure sine wave power, the Aims PWRIG500048120S really is the backbone of the setup. We are the experts when it comes to Aims and their 5KW 48 Volt pure sine inverter, if you have questions, please don’t hesitate to call us today!
Specifications:
- DC Input Voltage 48 V (41V-60V)
- Output Voltage no load 120Vac +/- 3%
- Continuous Power: 5000 Watts
- Surge Power: 10000 Watts
- Efficiency: 90%
- No Load Current (Fan On): 1.08A 48V
- No Load Current (Fan Off): 0.60A 48V
- Low Battery Shut Down: 40.0V
- Low Battery Return on Power: 42.5V
- High Battery Shut Down: 62.9V
- High battery return on Power: 58.8V
- Frequency Selection: 50/60hz
- Over Temperature Protection: -25ºC – 79ºC
- Cooling Fan on Temperature: 40ºC
- GFCI Outlets rated at 20A per block
Features:
- 5000 Watt continuous power
- 10000 Watt surge for 0.5 second
- 48 Volt DC input
- Pure sine wave
- 60hz or 50hz switch
- Highly efficient – improved output at low voltage
- 2 – GFCI Dual Outlet
- Direct connect AC Terminal Block
- Connector and cable for remote on/off switch
- Isolated ground & neutral
- Short circuit protection (GFCI and AC Breaker)
- On/off switch
- 5 Function Protection LED indicator
- AC Breaker
- Dual cooling fans thermally controlled
- Instruction manual
- 1 year tech support
- 1 Year Warranty Parts and Labor replacement
Dimensions:
Show the full description
- Unit Weight: 27.3 lbs.
- Unit Size L x W x H: 23 3/4 x 8 7/8 x 6 1/4
- Shipping Weight: 34 lbs.
- Shipping L x W x H: 29 1/8 x 13 3/4 x 11 3/4 inches
Specifications
| Continuous power | 5,000 W |
|---|---|
| Nominal voltage | 48 V |
| Weight | 34 lb |
|---|---|
| Dimensions | 29.13 × 13.75 × 11.75 in |
| Warranty | 1 Year |
|---|
| Brand | AIMS |
|---|---|
| SKU | PWRIG500048120S |
